Option 1: Use MAC address and serial number to add US Importer Zyxel Communications, Inc 1130 North Miller Street Anaheim, CA 92806-2001 Ĭopyright © 2020 Zyxel Communications Corp. See the User's Guide at for more information, including customer support and safety warnings.ĮU Importer Zyxel Communications A/S Gladsaxevej 378, 2.

Encrypt Key – If security is enabled, please enter the security password here.Using AES encryption is highly recommended. Encrypt Type – Adding encryption to the WDS link will protect packet transfers from middleman attackers.Remote MAC Address – Type in the MAC address of the other WAP access points (up to four) to establish WDS with.GREENFIELD – Use this option for 802.11n transmissions only.HTMIX – Use this option for 802.11b/g transmissions only.OFDM – Use this option for 802.11g transmissions only.CCK – Use this option for 802.11b transmissions only.Phy Mode – Select the Phy Mode the WAP should use to dictate the maximum size of packets during data transmission.Bridge – This option allows the WAP to function as a network bridge and establish a network link to other WAP access points.AP+Bridge – This option allows the WAP to function as a bridge to other WAP devices and an access point simultaneously.Click the dropdown and select a WDS feature option. Basic Setting – By default the WDS feature is set to “Disable”.Make the following changes from the WDS tab: Please be sure to take note of all the MAC addresses, this info is needed to configure the WDS.

A WDS link can be established with up to four remote WAP devices. To configure the wireless distribution system feature on the WAP please login to the web configuration screen and access menu, Configuration → Network → Wireless LAN and select the WDS tab. This allows a wireless network to be expanded between multiple access points without the need of a wired connection for the backbone. A Wireless Distribution System (WDS) is a wireless connection between two or more AP’s.
